The 391 series foot valves, all stainless steel, BSP male-male fitting, for common compatible fluids, charged water, glycol and more.
| Specification | Value |
|---|---|
| DN inches NPS | 3/8'' |
| Mounting direction | All positions |
| Thread standard | ISO 228-1 |
| Strainer basket material | Stainless steel AISI 316 |
| Application | Industry |
| DN | DN10 - 3/8'' |
| Fluid | Hot / Cold water |
| PS (bar) | 63 |
| Connections | BSP M |
| Screen (mesh) | 10/10° |
| TS max (°C) | 200 |
| TS min (°C) | -20 |
| Total height (mm) | 55 |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP M 3/8'' | 391003 | S1011166 |
€17.34
(excl. btw)
|
add to cart |
| BSP M 1/2'' | 391004 | S1011167 |
€17.93
(excl. btw)
|
add to cart |
| BSP M 3/4'' | 391005 | S1011168 |
€21.13
(excl. btw)
|
add to cart |
| BSP M 1'' | 391006 | S1011169 |
€25.14
(excl. btw)
|
add to cart |
| BSP M 1''1/4 | 391007 | S1011170 |
€28.64
(excl. btw)
|
add to cart |
| BSP M 1''1/2 | 391008 | S1011171 |
€33.06
(excl. btw)
|
add to cart |
| BSP M 2'' | 391009 | S1011172 |
€49.29
(excl. btw)
|
add to cart |
| BSP M 2''1/2 | 391010 | S1011173 |
€108.20
(excl. btw)
|
add to cart |
| BSP M 3'' | 391011 | S1011174 |
€114.64
(excl. btw)
|
add to cart |
| BSP M 4'' | 391012 | S1011175 |
€124.59
(excl. btw)
|
add to cart |
